主页 > 产品中心 > 连接器
DK-621-0011-P
产品图片仅供参考
欢迎索取产品详细资料

DK-621-0011-P

  • 所属类别：连接器
  • 产品名称：Conn Triaxial Solder ST Cable Mount PL
  • 厂商：TE
  • 生产批号：25+
  • 封装：连接器
  • 库存状态：有库存
  • 库存量：210
  • 最低订购量：1
  • 详细资料：点击查找DK-621-0011-P的pdf资料
  • 点击询价
联系我们 在线客服1 在线客服2 点击发送邮件
  • 产品介绍


Data Bus Discrete Connectors
Raychem D-621 and DK-621 series connectors are designed
specifically for MIL-STD-1553B data bus applications. In
addition to utilizing Raychem’s heat-shrink technology, the
D-621 and DK-621 series connectors also feature:
RUGGED RELIABILITY
• Low voltage drop and high reliability due to precisely controlled
solder terminations
• 1000-hour salt spray resistance, rugged construction
CONVENIENT
• Light weight, built-in strain relief
• Continuous 360° shield coverage
EASY INSTALLATION
• Low-skill assembly, low total installed cost
• Fast termination time of 1 to 2 minutes
• Installation Procedures: ES-61162 and ES-61420
VERSATILE
• Inspectable solder terminations
• Reworkable and repairable terminations
• Removable pin or socket contacts
COMPATIBLE
• Termination with Raychem MIL SPEC and MIL-STD-1553B data bus
cables, including EMP-hardened versions
• Specification: D-6025
