EMP-SM-3C-R10-D35
- 所属类别:连接器
- 产品名称:高压矩形连接器
- 厂商:amphenol
- 生产批号:24+
- 封装:连接器
- 库存状态:有库存
- 库存量:230
- 最低订购量:1
- 详细资料:
-
EMP-SM-3C-R10-D35
EMP SF 33 SC R10 D35
EMP SM 33 PC R10 D35
EMP SF 33 SC R18 D35
EMP SM 33 PC R18 D35
EMP SF 3C D35
EMP SM 6C D35
EMP SF 44 SC R10 D35
EMP SM 44 PC R10 D35
Material
■ Shell: Aluminium alloy
■ Insert: Thermoplastics
■ Contact: Copper alloy / silver plated / crimp type
■ Cable gland: Nickel plated brass
Mechanical and Climatical
■ Vibrations and Shocks: Category 1, Class B (EN61373)
■ Operating temperature: -55℃ to 125℃
■ IP Class: IP67
■ Durability: 500 cycles
Electrical data
■ Rated voltage: 3000 V r.m.s
■ Rated current: 250A max.
■ Cables: 25 to 70 mm2
■ Insulation resistance: 5000 MΩ Min.
■ Contact resistance: <0.3 mΩ
