AD7980ARMZRL7

优势和特点

产品详情
易于使用
μModule数据采集系统
全部有源元件皆由ADI公司设计
节省50% PCB面积
包含关键无源元件
SPI/QSPI/MICROWIRE™/DSP兼容串行接口
以菊花链形式连接多个ADAQ7980/ADAQ7988器件
多功能电源配置，1.8 V/2.5 V/3 V/5 V逻辑接口
高性能
16位分辨率、无失码
吞吐速率：1 MSPS
积分非线性(INL)：±8 ppm（典型值），20 ppm（最大值）
信噪比(SNR)：91.5 dB（典型值，10 kHz，单位增益）
总谐波失真(THD)：-105 dB (10 kHz)
零误差：±0.06 mV（典型值，单位增益）
零误差温度漂移：1.3 μV/°C（最大值）
低功耗
21 mW典型值(1 MSPS)
灵活的省电模式
24引脚5 mm × 4 mm小型LGA封装
出色的ESD额定值
3500 V人体模型(HBM)
1250 V场感应充电装置模型(FICDM)
宽工作温度范围：-55°C至+125°C
